เครื่องพ่นสี

GRACO ผู้นำด้านเครื่องพ่นสีและสเปรย์สี ระบบ Airless ที่มีประสิทธิภาพสูง ทนทาน เราเป็นตัวแทนจำหน่าย เครื่องปั๊มและพ่นสเปรย์สีและระบบลำเลียงของเหลวในอุตสาหกรรม พร้อมบริการหลังการขาย ซ่อมบำรุงและจำหน่ายอะไหล่ เครื่องพ่นสีระบบ Airless เรามีสินค้าให้เลือกหลากหลายตามต้องการ เช่น

 - ระบบพ่นสีสำหรับอุตสาหกรรมยานยนต์และสำหรับงานโครงสร้างและอาคาร (Spraying System)

 - อุปกรณ์พ่นโฟม (Air, Electric and Hydraulic Proportions)

 - เครื่องพ่นสีสำหรับธุรกิจขนาดย่อม (Spray Packages Unit)

 - ปืนพ่นสีระบบไฟฟ้าสถิต (Electrostatic Guns)

 - ปืนพ่นสีระบบไร้อากาศขับเคลื่อนด้วยลม (AIRLESS SPRAYERS)

 - ปั๊มจ่ายสีปริมาณสูงสำหรับอุตสาหกรรมรถยนต์ (Paint Circulation Systems)

 - ปั๊มไดอะแฟรมประสิทธิภาพสูง (Diaphragm Pumps)

 - อุปกรณ์ปั๊มจ่ายกาวและของเหลวที่มีความหนืดสูง (Sealer Pumps)

GRACO เป็นเครื่องพ่นสีที่ให้แรงดันคงที่ ทำงานโดยระบบไฟฟ้าและระบบลมหรือ Airless Spray ทำให้สีพ่นไม่ฟุ้งในขณะทำงาน ช่วยให้งานพ่นสีเสร็จเร็ว ช่วยประหยัดเวลา เครื่องมีความคงทน แข็งแรง

เครื่องพ่นสีระบบลม Airless Spray หรือระบบไม่มีอากาศ ทำงานโดยใช้แรงดันสูงดันสีออกจากหัวทิป หัวฉีดโดยผ่านปืนพ่นสี พ่นออกมาเป็นละออง ความกว้างความหนาตามขนาดของหัวทิป โดยตัวเครื่องพ่นสีดันสีออกมาโดยไม่ใช้ลม และพ่นออกมา ตามแรงดัน (pressure) ที่ได้ตั้งค่าไว้ โดยสามารถพ่น (Spray) ได้ทั้งแนวนอนและแนวดิ่ง ระบบการพ่นแบบแอร์เลส เป็นระบบที่ทำให้ของเหลวแตกตัว เป็นละอองเล็กๆ โดยไม่ใช้แรงดันอากาศ หรือแรงลมอัด

ในระบบแอร์เลส ของเหลวจะถูกปั๊มเข้าไปภายใต้แรงอัดกำลัง สูงผ่านไปยังหัวพ่น ระบบดังกล่าวจะส่งแรงดันอากาศ หรือลมไปยังของเหลวเพื่อสร้างละออง ของเหลวที่เคลื่อนที่ด้วยความเร็วอันเกิดจากแรงอัด จะทำให้เกิดการสเปร์ยละอองมาจากปืนแรงดันกำลังสูงจะผลักดันสีผ่านเข้าไปยังช่องพ่นขนาดเล็ก เมื่อสีกระทบกับอากาศ ก็จะกระจายตัวและแตกออกเป็นฝอย หรือละอองขนาดเล็กซึ่งเหมาะสำหรับงานพ่นสีน้ำหรือสีน้ำมัน สำหรับงานบ้านและงานอาคาร สามารถเลือกใช้กับหัว Tip สูงสุดถึงเบอร์ 0.021 โดยลูกสูบแบบพิสตั้น จะสร้างแรงดันต่อเนื่องที่ 207 บาร์ ทำให้สีแตกตัวเป็นละออง พ่นชิ้นงานได้อย่างดี สามารถพ่นสีได้ในอัตรา 1.8 ลิตร/นาที ใช้งานและทำความสะอาดง่าย





         Airless Accessories                   Eco Quip                              Electrostatic Spray           Fireproofing Material Sprayers       Foam & Polyuria Coating





    Paint Sprayers        Liquid Painting & Coating Equipment      Pump & Pump Transfer    Pumping process & Equipment  Sealant & Adhesive Supply system





       Tip & Accessories



สอบถามรายละเอียดเพิ่มเติมได้ที่

ฝ่ายขาย 02-720-4400-8




บริษัท ยูนิ-โรแยล แพค จำกัด

3 พัฒนาการ 50 ถนนพัฒนาการ แขวงสวนหลวง เขตสวนหลวง กรุงเทพ 10250

Tel:  02-720-4400-8

Fax:  02-720-4410

E-mail: salesurp@truemail.co.th

http://www.เครื่องพ่นสี.com

http://www.xn--42cg8ctax9br2em1g8dd.com







Electrostatic Spray





Pro Xp Electrostatic Spray Guns
We took our trademark, high performing electrostatic spray guns and made them better. They are smaller, lighter and designed to maximize your profits. Available in 40, 60 and 85 kV, the Pro Xp electrostatic spray gun also has a Round Spray option for when you need a bell-shaped pattern and a High Conductivity version for when you have low resistivity material.







Pro Xp Air Spray: For low pressure spraying with an isolation system including the WB100.

Pro Xp Air-Assist: For high pressure spraying with an isolation system including the WB3000. Delivers a fine finish with an AEF or AEM tip.

Pro Xp MR: Low pressure spraying with a fine finish spray tip. Delivers fine atomized particles required for mold release applications. Connects to an isolation system, including the WB100 and sprays with an AEM or AEF spray tip.


  • Superior atomization for a high quality finish
  • Internal power supply allows for quick installation and easy service
  • Lightweight and compact design increases operator comfort
  • Smart display for increased operator feedback
  • Rugged design outlasts the competition
  • Easy installation – uses only air to generate electrostatic power


Electrostatic Air Spray Waterborne Guns
Maximum Working Fluid Pressure
100 psi
Maximum Working Air Pressure
100 psi
Minimum Air Pressure at Gun Inlet
45 psi
Maximum Fluid Operating Temperature
120°F
Short Circuit Current Output
125 microamperes
Voltage Output Energy
0.35 J with fluid hose 24M733 installed. L60T17 and L60T18: 60 kV. L60M17, L60M18, and L60M19: 30–60 kV
Sound Power (measured per ISO Standard 9216)
at 40 psi: 90.4 dB(A) at 100 psi: 105.4 dB(A)
Sound Pressure (measured 1 m from gun)
at 40 psi: 87.0 dB(A) at 100 psi: 99.0 dB(A)
Air Inlet Fitting
1/4 npsm(m) left-hand thread
Fluid Inlet Fitting
Custom inlet for Graco waterborne fluid hose.
Isolation Enclosure Air Inlet Fitting
1/4 npt
Isolation Enclosure Fluid Inlet Fitting
3/8 in. OD tube fitting
Wetted Parts
Gun: Stainless Steel, PEEK, UHMWPE, Fluoroelastomer, Acetal, Nylon, Polyethylene, Tungsten Wire. Waterborne Fluid Hose: PTFE. Suction Tube: Polyethylene, Stainless Steel. Triton Pump: See manual 309303.






Fireproofing Material Sprayers





Passive fire protection (PFP) coatings make structures more resistant to fire by insulating structural steel from high temperatures and as a result, buy time for the evacuation before structural collapse.

The Graco XM™ PFP Plural-Component Sprayer offers data reporting technology, so you can confirm that epoxy intumescent coatings are sprayed on-ratio, at requirements set by the manufacturer. The XM PFP is easy to use, maintains consistent temperature control and offers precise ratio control.







Count on Graco XM PFP for accurate, on-ratio mixing

  • Handles two-part epoxy intumescent fire protection coatings from 1:1 to 10:1
  • Provides precise ratio control
  • If off-ratio conditions occur, the system will automatically stop
  • Offers data reporting for verification the material was properly applied
  • Monitors, tracks and collects data for: mix ratio, pressure, temperature, flow rates and material usage
  • USB port to easily download data reports
  • Accurate, on-ratio mixing reduces material waste
  • Virtually eliminates the difficult task of removing improperly mixed material
  • Offers peace of mind with “set and forget” parameter settings


Manuals


XM PFP
U.S.
Metric
Mix Ratio Range
1:1-10:1 (in 0.01 increments)
Ratio Tolerance Range (before alarm)
+/- 5%
Maximum Flow Rate (measured with oil)
3 gallons per minute
Fluid Viscosity Range
Handles mastic materials which are loaded into heated tankswith ram-fed priming piston pumps
Air Inlet
1 in. npt(f)
Fluid Inlets
Pail (Feed Pumps)
Maximum Fluid Working Pressure for A and B Materials
6000 psi
Maximum Fluid Working Pressure for Flushing
4500 psi
Maximum Fluid Working Pressure for Heating
100 psi
Maximum Fluid Temperature
160°F
System Inlet Supplied Air Pressure Range
80-150 psi
Maximum Pump Air Pressure
100 psi
Maximum Tank Air Pressure
90 psi
Air Filtration
40 micron main filter, 5 micron control air filter
Ambient Operating Temperature Range
32 to 130°F
Ambient Storage Temperature Range
30 to 160°F
Environmental Conditions Rating
Altitude up to 13,123 ft
Sound Pressure *
86 dBA at 100 psi
Sound Power **
98 dBA at 100 psi
System Weight (empty, no fluid)
2175 lb
Air Consumption
Minimum
100 scfm
Maximum
250 scfm
Typical Application
125-175 scfm
Power Requirements
Voltage (can be set with jumpers)
Option 1: 220-240V, 3 phase DELTA (3 wire plus ground) Option 2: 380-400V, 3 phase WYE (4 wire including neutral plus ground)
Wattage
18,400 watts (23,400 with optional flush water heater)
Amps
240V, 3-phase models: 65 Amps per phase full load: 380V, 3-phase models: 38 Amps per phase full load
Wetted Parts
Suction Tube (Flush)
Aluminum
Tanks
Stainless Steel
Flush Pump
Carbide, PTFE, stainless steel, UHMWPE
Hoses
Nylon
A and B Metering and Feed Pumps
Carbon steel, alloy steel, stainless steel, zinc and nickel plating, ductile iron, tungsten carbide, PTFE
Dosing Valves
Carbon Steel, nickel plating, carbide, polyethylene, leather
Manifold
Carbon steel, nickel plating, carbide, stainless steel, PTFE
Mixer
Stainless steel housing with stainless elements
Approvals
Machine
CE, ETL
Pressure Tanks
ASME, CE
Notes
* Sound pressure measured 3.3 feet (1 meter) from equipment.
** Sound power measured per ISO-9614-2.









Foam & Polyuria Coating

Reactor E-20

Reactor E-XP1

Reactor 2 E-30

Reactor A-25




Liquid Painting & Coating Equipment

AIRSPRAY GUN Manual & Auto

AIRSPRAY HVLP GUN Manual & Auto

Air-Assisted Spray Guns Manual & Auto

Manual & Auto Electrostatic Guns

Manual & Auto Electrostatic Air-Assisted Guns

PRO Xs Air-Assisted Guns

Manual & Auto Airless Spray Gun

XTR



Pump & Pump Transfer

1. Air Power

Diaphargm Pump

Piston Pump

Pressure Tanks and Pressure Cups

2. Electric Power & Electric Product Specification

3. Gas Power

Texture Sprayers
– Electric Airless Texture Sprayer
– Pumping System for Texture Spraying
– Gas-Powered Texture Sprayer

Cost-Effective Hydraulic Proportioners , Air-Driven Proportioner for Spraying Foam



Pumping process & Equipment

Husky 3300 Air-Operated Double Diaphragm Pumps

3 inch Positive Displacement Double Diaphragm Pump

AODD pumps with 3 inch (76.2 mm) connection available in aluminum, polypropylene and stainless steel

The Husky 3300, 3 inch (76.2 mm), pneumatic double diaphragm pumps feature a four bolt joint design, which provides even sealing pressure for leak-free operation and a three-piece manifold for increased installation flexibility. Available in aluminum, polypropylene and stainless steel.

  • Expanded material offering to handle numerous applications
  • Flow rates up to 300 gpm (1,135 lpm)
  • Modular stall-resistant air valve design
  • Complete 3 inch family of diaphragm pumps available in aluminum or polypropylene center sections
  • Heavy-duty construction
  • Faster change over with spring loaded pilot valves
Husky 3300 Air-Operated Diaphragm Pump
Maximum fluid working pressure
Aluminum or Stainless Steel with Aluminum Center Section
125 psi
Polypropylene or Stainless Steel with Polypropylene Center Section
100 psi
Air pressure operating range**
Aluminum or Stainless Steel with Aluminum Center Section
20-125 psi
Polypropylene or Stainless Steel with Polypropylene Center Section
20-100 psi
Air consumption
All pumps
90 scfm at 70 psi, 100 gpm
Maximum air consumption*
Aluminum or Stainless Steel with Aluminum Center Section
335 scfm
Polypropylene or Stainless Steel with Polypropylene Center Section
275 scfm
Maximum free-flow delivery*
Standard diaphragms
300 gpm at 125 psi
Standard diaphragms
280 gpm at 100 psi
Overmolded diaphragms
270 gpm at 125 psi
Overmolded diaphragms
260 gpm at 100 psi
Maximum Pump Speed*
Standard diaphragms
103 cpm at 125 psi
Standard diaphragms
97 cpm at 100 psi
Overmolded diaphragms
135 cpm at 125 psi
Overmolded diaphragms
130 cpm at 100 psi
Maximum suction lift (varies widely based on ball/seat selection and wear, operating speed, material properties, and other variables)*
Dry
16 ft.
Wet
31 ft.
Recommended cycle rate for continuous duty
35 – 50 cpm
Recommended cycle rate for circulation systems
20 cpm
Maximum size pumpable solids
1/2 in.
Fluid flow per cycle**
Standard diaphragms
2.9 gal
Overmolded diaphragms
2.0 gal
Ambient Temperature
Minimum ambient air temperature for operation and storage. NOTE: Exposure to extreme low temperatures may result in damage to plastic parts
32° F
Noise (dBa)***
Sound Power
99.1 at 50 psi and 50 cpm, 106.1 at 125 psi and full flow
Sound Pressure
91.5 at 50 psi and 50 cpm 98.2 at 125 psi and full flow
Inlet/Outlet Sizes
Fluid inlet – Polypropylene
3 in. ANSI/DIN flange
Fluid inlet – Aluminum
3 in.-8 npt or 3 in.-11 bspt with 3 in. ANSI/DIN flange
Fluid inlet – Stainless Steel
3 in.-8 npt or 3 in.-11 bspt
Air Inlet – all pumps
3/4 in. npt(f)
Wetted parts
All pumps
Materials chosen for seat, ball, and diaphragm options, plus the pump’s material of construction – aluminum, polypropylene, or stainless steel. Aluminum pumps also have carbon-coated steel
Non-wetted external parts
Polypropylene
stainless steel, polypropylene
Aluminum
aluminum, coated carbon steel
Stainless Steel
stainless steel, polypropylene or aluminum (as used in center section
Weight
Polypropylene
200 lb
Aluminum
150 lb
Stainless Steel
255 lb
Notes
* Maximum values with water as media at ambient temperature. Water level is approximately 3 feet above pump
** Startup pressures and displacement per cycle may vary based on suction condition, discharge head, air pressure, and fluid type.
*** Sound power measured per ISO-9614-2. Sound pressure was tested 3.28 ft (1 m) from equipment.
Santoprene® is a registered trademark of the Monsanto Co.
Loctite® is a registered trademark of the Loctite Corporation

Husky 15120 Air-Operated Double Diaphragm Pumps

1.5 inch Positive Displacement Double Diaphragm Pump

AODD pumps with 1-1/2 inch (38.1 mm) connection available in polypropylene and PVDF

Our new Husky 15120 pneumatic double diaphragm pumps have a single piece polypropylene center section for increased reliability and chemical compatibility, plus a patented, high-reliability modular air valve that is online serviceable. Design improvements include the overmolded frame which provides improved reliability and helps to eliminate fluid leakage and an updated diaphragm design that increases flow with flow rates up to 120 gpm (454 lpm) – making it one of the most efficient pumps on the market.

  • 1-1/2 in (38.1 mm) ANSI center and end-porting options available
  • High flow – 120 gpm (454 lpm) in a compact, portable size
  • Fluid pressure to 125 psi (8.6 bar, 0.86 MPa)
  • Lube-free operation
  • Available in polypropylene and PVDF
Husky 15120 Air-Operated Diaphragm Pump
Maximum fluid working pressure
125 psi
Air pressure operating range
20 to 125 psi
Air inlet size
1/2 in. (npt(f)
Air exhaust size
1 in.
Fluid inlet and outlet size (ANSI/DIN flange)
1.5 in
Maximum suction lift (reduced if balls don’t seat well due to damaged balls or seats, lightweight balls, or extreme speed of cycling)
Wet: 31 ft, Dry: 16 ft
Maximum size pumpable solids
1/4 in.
Minimum ambient air temperature for operation and storage. NOTE: Exposure to extreme low temperatures may result in damage to plastic parts.
32° F
Air Consumption
43 scfm at 70 psi, 60 gpm
Maximum Air Consumption
85 scfm
Noise (dBa): Sound power measured per ISO-9614–2. Sound pressure was tested 3.28 ft (1 m) from equipment.
Sound Power
90.9 at 70 psi and 50 cpm, 102.1 at 100 psi and full flow
Sound Pressure
83.6 at 70 psi and 50 cpm, 95.7 at 100 psi and full flow
Fluid flow per cycle
1–piece bolt-through diaphragms
0.63 gallons
2–piece bolt-through diaphragms
0.66 gallons
Overmolded diaphragms
0.59 gallons
Maximum free-flow delivery
1–piece bolt-through diaphragms
122 gpm
2–piece bolt-through diaphragms
120 gpm
Overmolded diaphragms
115 gpm
Maximum pump speed
1–piece bolt-through diaphragms
192 cycles per minute
2–piece bolt-through diaphragms
183 cycles per minute
Overmolded diaphragms
195 cycles per minute
Weight
Polypropylene
57 lb
PVDF
74 lb
Wetted Parts
Wetted parts include material(s) chosen for seat, ball, and diaphragm options, plus the pump’s material of construction: Polypropylene or PVDF
Non-wetted external parts
stainless steel, polypropylene





Sealant & Adhesive Supply system

ExactaBlend AGP

Advanced Glazing Proportioner

For sealant and adhesive applications in curtainwall and insulating glass

The Graco ExactaBlend AGP (Advanced Glazing Proportioner) provides on-ratio dispensing of two-component sealants and adhesives for curtainwall, insulating glass and other applications. The variable ratio ExactaBlend AGP offers advanced technologies at an affordable price.

Superior mixing and ratio assurance for the glass industry

  • Easy to operate
  • Green light indicates on-ratio dispensing
  • System automatically shuts down if off-ratio conditions exist
  • Optimal mixing and on-ratio proportioning capabilities for quality assurance
  • Quick and easy base purge reduces material waste
  • Optional data download provides reports on ratio, flow rate and material usage
ExactaBlend AGP Advanced Glazing Proportioner
Maximum fluid working pressure : MD2 or Ultra-lite with flexible hose mixer Installed
3000 psi
Maximum fluid working pressure :Ultra-lite with Tri-core mixer Installed
4000 psi
Incoming Air pressure required: Startup pressures and displacement per cycle may vary based on suction condition, discharge head, air pressure, and fluid type.
80-100 psi
Maximum operating temperature
120°F
Voltage range
90-264 VAC 50/60 Hz 1 phase
Maximum amperage
4
Sound pressure: Sound pressure measured 3.3 feet (1 meter) from equipment.
82 dB(A)
Wetted parts: Refer to specific component manual for more details.
Zinc-plated carbon steel, aluminum ram plate, nitrile rubber wipers, chrome, stainless steel, UHMW polyethylene, PTFE, nylon, Buna-N
Inlet/Outlet Sizes
Fluid outlet base
1/2 npt (f)
Fluid outlet catalyst
1/4 npt (f)
Air inlet size
3/4 npt (f)
Weight
All models
865 lb.





Visitors: 1,468
